Radial mounting for maximum rigidity and firm, consistent pedal
Aluminium pistons as standard, stainless steel pistons available as an option to reduce heat transfer to brake fluid
2kg anti-knock back springs
Hard stainless steel wear plates
Pad retaining wire for fast pad change
Common leading / trailing installation by switching bleed screw and inlet
Internally ported, no external fluid transfer pipe
Disc diameter range Ø250 – 300mm
Disc thickness range 8 – 10mm
Fluid inlet 3/8-24 UNF (-3) female
Dry weight 0.97Kg excluding pads
Alcon pad reference: 3451/42 pad shape, area 49.2cm2 or 3451/47 pad shape, area 56.0cm2, 14mm thick, 63.4mm long, area 49.2cm2
