Radial mount for maximum rigidity and firm, consistent pedal
Aluminium pistons as standard, stainless steel pistons available as an option to reduce heat transfer to brake fluid
2kg anti-knock back springs
Remove pad retainer bolt and sleeve to change pads
Stainless steel fluid transfer pipe
Disc diameter range Ø250 – 304mm
Disc thickness range 25.4 – 28mm
Fluid inlet 3/8-24 UNF (-3) male
Dry weight 1.9kg excluding pads
Alcon pad reference 4463/39 area 80cm2 or 4463/42 area 92cm2, 16mm thick, 113.5mm long
